Working Temperature：-100～-145°C
Maximum Load：3500W@-100℃
Pumping Speed：250000L/sec
Professional control panel,RS485 available
Strength guarantee: 20 years of manufacturing experience,
24-hour after-sales service
* Working Temperature：-100～-145℃；
* Maximum Load：3500W
* Cryocoil Surface：2.0㎡
* Pumping Speed：250000L/sec
* Cooling mode：Water-Cooled
* Net weight：475Kg
* Power requirements：380V/3Ph/50Hz/11.6kW
* Overall dimension：750W×920D×1650Hmm
Main features of VaporCold water vapor cryochiller:
* Rapid water vapor trapping, shorten the vacuum pumpdown time by 25-90%;
* Improve coating quality, for the best films, better adhesion and more reproducible deposition;
* Fast cooling, cool to -100℃ within 3 minutes, with a minimum of -150℃;
* Fast defrosting, defrost to 20℃ within 3 minutes ;
* The refrigeration system is optimized to cool down again within 3 minutes;
* With industrial PLC and touch panel, Process data logging is supported;
* International brand refrigeration compressor, environmental friendly refrigerant blend;
* International standard refrigeration port, which can be designed as single or two-way load outputs;
* Display and logging of inlet temperature and outlet temperature of single or two-way load;
* Display and logging of internal temperature, water cooling temperature,discharge temperature and discharge pressure;
* The defrosting temperature can be set freely, and will be prompted automatically after defrosting;
* Alarm protection for high discharge temperature and pressure;
* Alarm protection for insufficient water cooling and high water temperature;
* The valve box is placed in front,convenient for operation;
* Local mode and remote mode, convenient for combination control;
* RS485 communication interface to facilitate connection to upper computer.
* Small Footprint
* Attain Deeper Vacuum
* Fast Cool Down for shorter cycle times
* Decrease Pump down Times by 25% to 90%
* More Efficient Water Vapor Pumping
* Fast Defrost and fast cool down again
* Improve Coating Quality and Quantity of products
* Eliminate Costly LN2 Usage For Fast Payback
